BNT-1000AP
AC Input Capacity on Battery 1000VA
AC Input Voltage 100V or 110V/115V/120V or 220V/230V/240V +/- 25% at line input
AC Input Frequency 50 or 60 Hz+/-5% (auto sensing)
C Output Voltage Simulated sine wave at 100V or 110V/115V/120V +/- 5% for 120V model or 220V/230V/240V +/- 5% for 230V model
AC Output Frequency 50 or 60 Hz +/- 0.5%
Protection Spike 480 Joules / 2ms
Protection Overload UPS automatic shutdown if overload exceeds 110% nominal at 60 sec and 130% at 3 sec
Battery Typical 6 hours (to 90% of full capacity)
Battery Backup Time Full Load 8 minutes
Alarm Battery Backup Slow beeping sound (about 0.47 Hz)
Alarm Battery Low Rapid beeping sound (about 1.82Hz)
Interface RS-232YES
Environment Ambient 3,500 meters max. elevation, 0-95% humidity non-condensing, 0-40 deg c
D-Link NTP-001 Punch Down Tool
Color-coded yellow handle on the cut side of the tool
Adjustable low and high impact force settings
Reversible blades for seating/cut or seating only for jumper wires.
Spare blade storage in the handle reduces installation time
Blades are made from heat-treated, high-carbon tool steel with a black-oxide
Rust-resistant finish and a precision-ground cutting surface for long life
